Home Assistant + Docker + Z-Wave + Raspberry Pi

A few years back I had a SmartThings Hub and for the most part it worked great. It was simple to setup, can be accessed anywhere, and for the most part automatically updated itself. Unfortunately, with the acquisition of it by Samsung, it seems to have turned into bloatware with poor responsiveness, the mobile application’s UI is horrific, and they have a less than desirable security/privacy policy.

Luckily, the open source community has thrown together Home Assistant, an open source home automation project backed by hundreds/thousands of individuals. Over the years, they have now brought native support for mobile devices, at time of writing this there are 1500+ integrations for dang near any device, and the software puts you in control of who has access to and where your data is accessible.

The one trade-off though is while Home Assistant works well and is very extensible, the documentation and usability of the application can be overwhelming to understand for someone new to home automation, unfamiliar with Linux/Open Source technologies, or new to debugging/command line interfaces.

In this case, I’ve tried to document a crash course in getting Home Assistant up and running as quickly as possible for those that want to get started with Z-Wave devices and Home Assistant.

Hardware

You can leverage pretty much any hardware with Home Assistant, but here are the two items I used in my venture. Home Assistant has a full list of recommendations for what hardware to use for Home Assistant (https://www.home-assistant.io/getting-started/#suggested-hardware) as well as what Z-Wave controllers are supported (https://www.home-assistant.io/docs/z-wave/controllers/).

Update your Raspberry Pi

First things first, update your Raspberry Pi with the latest updates. Open up Terminal or SSH to your Raspberry Pi and execute the following command:

sudo apt-get update && sudo apt-get upgrade

Prepare your Z-Wave USB Stick

Plug in your Z-Wave USB stick. Once plugged in, we need to find the device path so that we can reference it for Home Assistant. Execute the lsusb command to find your device ID. In this case, you can see my device ID begins with 0658.

[email protected]:/dev# lsusb
Bus 002 Device 001: ID 1d6b:0003 Linux Foundation 3.0 root hub
Bus 001 Device 003: ID 0658:0200 Sigma Designs, Inc. Aeotec Z-Stick Gen5 (ZW090) - UZB
Bus 001 Device 002: ID 2109:3431 VIA Labs, Inc. Hub
Bus 001 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub

Next, let’s find what the device path is for the USB stick. You can do this by executing the following command: dmesg | egrep ‘0658|acm’ Please note, if you purchased a difference device, 0658 may be a different number. In this case, you can see my device is presented on ttyACM0.

[email protected]:/dev# dmesg | egrep '0658|acm'
[    1.405327] usb 1-1.2: New USB device found, idVendor=0658, idProduct=0200, bcdDevice= 0.00
[    3.468875] cdc_acm 1-1.2:1.0: ttyACM0: USB ACM device
[    3.471348] usbcore: registered new interface driver cdc_acm
[    3.471359] cdc_acm: USB Abstract Control Model driver for USB modems and ISDN adapters

Install Docker

Home Assistant doesn’t require Docker, but by leveraging Docker you can easily copy/backup your configuration and simply redeploy the container if something goes wrong. As updates are made, you can simply remove your container and redeploy. To install Docker, execute the following command:

curl -sSL https://get.docker.com | sh

Deploy Home Assistant Docker Container

Once Docker is installed, you can deploy the container from Docker Hub. Docker Hub is a public repository that has tons of different prebuilt containers to deploy. Here you can find the official homeassistant containers: https://hub.docker.com/u/homeassistant

To deploy the container, execute the following line, replacing the following variables with your desired configuration:

  • –name=”the name of your container
  • -e “TM=YourTimezone
  • –device=/dev/ttyACM0
    • This allows the container to leverage the Z-Wave USB device. Make sure you specify the path to your device found in the previous step
  • -v /home/docker/home-assistant:/config
    • This is the path that the home assistant configuration files should be stored to. You can specify a fileshare or other path to place your configuration files.
  • –net=host homeassistant/raspberrypi4-homeassistant:stable
    • The first half of this is the container you wish to deploy and the second half is the version. You can find all of Home Assistant’s official containers here: https://hub.docker.com/u/homeassistant
sudo docker run --init -d --restart=always --name="home-assistant" -e "TZ=America/Chicago" --device=/dev/ttyACM0 -v /home/docker/home-assistant:/config --net=host homeassistant/raspberrypi4-homeassistant:stable

Setup Home Assistant

Give the container a few minutes to deploy and configure itself for the first time. After a few minutes, try opening your web browser and navigating to the IP address assigned to your machine, using port number 8123: http://192.168.1.2:8123/

When the page loads, it should first ask for your Name, Username, and Password. This is the username and password you will use to login to Home Assistant.

Next, specify the location of where your Home Assistant deployment is located. Oddly enough, you cannot type in a location, but you can place the pin near your location by dragging the map around and clicking once to set the pin.

Once you click Next, Home Assistant may have already found a few devices connected to your network. You can add them now or skip and add them later.

Tell Home Assistant to use your Z-Wave USB Stick

Although we granted access to the container to use the Z-Wave USB Stick, you need to tell Home Assistant how to leverage the device. To do so, you will need to open up Terminal or SSH to your machine and edit the configuration.yaml file to point to the device. Before we get into modifying the configuration.yaml file, first execute the following command to generate a Z-Wave Security Key. This key may be required by Z-Wave security devices (Door Locks, Keypads, etc), as an extra layer of security. More information on this can be found here: https://www.home-assistant.io/docs/z-wave/adding#network-key

Execute the following command via Terminal or SSH:

cat /dev/urandom | tr -dc '0-9A-F' | fold -w 32 | head -n 1 | sed -e 's/\(..\)/0x\1, /g' -e 's/, $//'

Once you execute the command, it should give you a string of characters that look something like:

“0x01, 0x02, 0x03, 0x04, 0x05, 0x06, 0x07, 0x08, 0x09, 0x0A, 0x0B, 0x0C, 0x0D, 0x0E, 0x0F, 0x10”

Next, we need to edit the configuration.yaml file, which can be found in the path specified when the Docker container was deployed (using the -v parameter). For the purpose of this article, /home/docker/home-assistant/configuration.yaml is where the file is located. Using your favorite text editor, add the following lines of code:

zwave:
  usb_path: /dev/ttyACM0
  network_key: "0x01, 0x02, 0x03, 0x04, 0x05, 0x06, 0x07, 0x08, 0x09, 0x0A, 0x0B, 0x0C, 0x0D, 0x0E, 0x0F, 0x10"
configuration.yaml file with Z-Wave configuration

Once saved, go back to Home Assistant and click the Gear icon and then select Server Controls

Select the Restart button to restart Home Assistant. Any time you make a change to the configuration.yaml file, you will need to restart Home Assistant to pickup the configuration changes.

Click OK to Restart

Upon restart, navigate back to the Gear icon and you should see a new entry in the Config portal for Z-Wave. If you do not see the “Z-Wave” section, scroll down to the troubleshooting step at the end of this article.

Add a Z-Wave device

Once you see that your Z-Wave network has started, adding a device is a piece of cake. First click the Add Node button. When you click the button, nothing will happen, but go ahead and put your device in inclusion mode. Once the device is in inclusion mode, Home Assistant should automatically add the device.

At this point, if you navigate back to Configuration (Gear icon) and select Devices

You should see your newly added Z-Wave device!

At this point, you can select the Device to give it a friendly name or start to work on building your own home automation actions.

Hope this helped! If you have any comments or suggestions on how to improve this guide, please drop it below.

Troubleshooting Missing Z-Wave Configuration

The first time I ran through this, I noticed I was missing the Z-Wave configuration tile after making changes to the configuration.yaml file. It turned out I specified the wrong device path in the configuration file. To verify, you can check the logs from your Docker container by executing the following command in your Terminal or via SSH. (Replace home-assistant with the name of your container if you specified something else)

sudo docker logs home-assistant

In my case, I had the following error:

2020-02-16 21:08:01 INFO (MainThread) [homeassistant.components.scene] Setting up scene.homeassistant
2020-02-16 21:08:02 INFO (MainThread) [homeassistant.components.zwave] Z-Wave USB path is /dev/ttyACM01
2020-02-16 21:08:02 ERROR (MainThread) [homeassistant.config_entries] Error setting up entry Z-Wave (import from configuration.yaml) for zwave
Traceback (most recent call last):
  File "/usr/local/lib/python3.7/site-packages/openzwave/option.py", line 78, in __init__
    raise ZWaveException(u"Can't find device %s : %s" % (device, traceback.format_exception(*sys.exc_info())))
openzwave.object.ZWaveException: "Zwave Generic Exception : Can't find device /dev/ttyACM01 : ['NoneType: None\\n']"

During handling of the above exception, another exception occurred:

Traceback (most recent call last):
  File "/usr/src/homeassistant/homeassistant/config_entries.py", line 215, in async_setup
    hass, self
  File "/usr/src/homeassistant/homeassistant/components/zwave/__init__.py", line 369, in async_setup_entry
    config_path=config.get(CONF_CONFIG_PATH),
  File "/usr/local/lib/python3.7/site-packages/openzwave/option.py", line 81, in __init__
    raise ZWaveException(u"Error when retrieving device %s : %s" % (device, traceback.format_exception(*sys.exc_info())))
openzwave.object.ZWaveException: 'Zwave Generic Exception : Error when retrieving device /dev/ttyACM01 : [\'Traceback (most recent call last):\\n\', \'  File "/usr/local/lib/python3.7/site-packages/openzwave/option.py", line 78, in __init__\\n    raise ZWaveException(u"Can\\\'t find device %s : %s" % (device, traceback.format_exception(*sys.exc_info())))\\n\', \'openzwave.object.ZWaveException: "Zwave Generic Exception : Can\\\'t find device /dev/ttyACM01 : [\\\'NoneType: None\\\\\\\\n\\\']"\\n\']'

Here you can see I accidentally specified /dev/ttyACM01 vs /dev/ttyACM0. Simply updating the configuration.yaml file with the correct device path solved the issue.

Setting up an email server on a RaspberryPI (Postfix+Dovecot+MariaDB+Roundcube)

There’s a few things in this journey that you should be aware of when running your own mailserver before we begin.

  1. Invest in a static public IP
  2. Don’t open mail relay
  3. Leverage proper DNS records to help mitigate your email from being marked spam
  4. Leverage something to scrub your email
  5. Don’t open mail relay
  6. Don’t open mail relay
  7. Verify your domain or IP address hasn’t been placed on a blacklist from a previous owner

In my career in doing IT, handling email is one of the most tidiest tasks to setup/maintain due to so many moving pieces; many of which may be out of your control. Dealing with spam, blacklisting, having emails non-deliverable for several reasons, handling dns records, certificates, etc…. it’s sometimes worth paying a few extra bucks to have someone else host your email and have peace of mind the message will be delivered. That being said, if you have the extra time on your hands and like the challenge of solving problems, here’s a quick way to get started.

Preamble

This guide took me several hours to compile through trial and error. If you have any thoughts, notice any errors/typos, or have ideas on how to further secure/optimize, please leave feedback below to further improve this guide. Thank you and good luck on the deployment of your mail server!

Assumptions

  • You have previously followed my guide on building a LEMP stack
  • You are running Ubuntu or Debian as per the above guide (you can still follow this guide, you may have to slightly change which commands you use for your distribution — configuration should remain the same though)

DNS

Let’s first start at getting your DNS records configured properly. This guide will talk about configuring MX, SPF, and PTR records. We won’t be covering Domain Keys in this article, maybe in a separate article if someone donates to my paypal on the right side of the website ūüėČ

MX Record

Via your nameservers, add a new mx record for your domain name. Here’s a list of tutorials for some of the major domain registrars:

SPF Record

Contrary to many websites that say you need to create a “SPF” record type, the SPF record type was never ratified by RFC standards. In this case, the proper way to create a SPF record is via a TXT record with the SPF value (as per RFC 7208).

You can leverage my SPF generator to create a new TXT record in the root of your domain.

PTR Record

To help decrease the odds of your emails being labeled as spam, I’d recommend creating a PTR record that will resolve your IP address to a DNS name (we call this a reverse lookup). For example, if my mail server’s domain name was mail.mydomain.com and it resolved to 123.123.123.123, I would create a PTR record for 123.123.123.123 that points to mail.mydomain.com.

In many cases, you will need to either work with your ISP (Internet Service Provider) or domain registrar if you own your own IP block to make changes to the record for your IP address block.

When you are ready, you can leverage the nslookup command on Windows to validate the name from the IP address.

nslookup 123.123.123.123

Or on linux you can leverage the host command to verify the reverse lookup as well:

host 123.123.123.123

Get the OS ready

Download the latest packages and actually perform any updates.

sudo sh -c 'apt update && apt upgrade'

Prepare MariaDB for virtual users/aliases

One of the primary reasons we need to configure a database is it is what will contain the information about all of our users and their corresponding email addresses (aliases). To do so, we need to create 3 new tables inside of a new database.

Login to the database

sudo mariadb -u root -p

Create the database, database user, and tables

Create a new database for our users (in this case, I’m calling the database mailserver). Note: This command must be run in the context of mariadb, this is not a bash command.

create database mailserver;

Create a new user called mailuser, grant them access to the entire database, require the user to only create connections from 127.0.0.1 (localhost), and specify a password for the user.

GRANT SELECT ON mailserver.* TO 'mailuser'@'127.0.0.1' IDENTIFIED BY 'mysupersecretpassword';

Execute the following command to apply the changes

FLUSH PRIVILEGES;

Create a table for each of the domain names we will leverage for our email addresses.

CREATE TABLE `mailserver`.`virtual_domains` (
  `id` int(11) NOT NULL auto_increment,
  `name` varchar(50) NOT NULL,
  PRIMARY KEY (`id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;

Create a table that will hold each of the users that will need mailboxes.

CREATE TABLE `mailserver`.`virtual_users` (
  `id` int(11) NOT NULL auto_increment,
  `domain_id` int(11) NOT NULL,
  `password` varchar(106) NOT NULL,
  `email` varchar(100) NOT NULL,
  PRIMARY KEY (`id`),
  UNIQUE KEY `email` (`email`),
  FOREIGN KEY (domain_id) REFERENCES virtual_domains(id) ON DELETE CASCADE
) ENGINE=InnoDB DEFAULT CHARSET=utf8;

Create a table that will hold aliases (additional email addresses) for a particular user.

CREATE TABLE `mailserver`.`virtual_aliases` (
  `id` int(11) NOT NULL auto_increment,
  `domain_id` int(11) NOT NULL,
  `source` varchar(100) NOT NULL,
  `destination` varchar(100) NOT NULL,
  PRIMARY KEY (`id`),
  FOREIGN KEY (domain_id) REFERENCES virtual_domains(id) ON DELETE CASCADE
) ENGINE=InnoDB DEFAULT CHARSET=utf8;

Insert a new user into the database

First, we need to add our first domain name into the domains table

INSERT INTO `mailserver`.`virtual_domains`
  (`name`)
VALUES
  ('mydomain.com');

Second, we need to create the user. Replace mysupersecretpassword with your password.

INSERT INTO `mailserver`.`virtual_users`
  (`domain_id`, `password` , `email`)
VALUES
  ('1', ENCRYPT('mysupersecretpassword', CONCAT('$6$', SUBSTRING(SHA(RAND()), -16))), '[email protected]');

Third, we can optionally specify an alias (secondary email address) for the user.

INSERT INTO `mailserver`.`virtual_aliases`
  (`domain_id`, `source`, `destination`)
VALUES
  ('1', '[email protected]', '[email protected]');

Type exit once you are done to leave the context of MariaDB.

Install Packages for Postfix and Dovecot

Postfix is what we call a Mail Transport Agent (MTA) and is responsible for actually sending/receive the messages from the internet. Later, we will talk about Dovecot which will be our MDA (Mail Delivery Agent) (what actually interacts with the mailbox).

The following command will install postfix, dovecot, and pull the packages to interact with MySQL. Although these are labeled MySQL, they should interact fine with MariaDB.

sudo apt-get install postfix postfix-mysql dovecot-core dovecot-imapd dovecot-lmtpd dovecot-mysql

During the installation of Postfix, you will be prompted to configure the connection type to the mail server. In this case, select Internet Site for the mail configuration.

On the second installation prompt, it will ask for the domain name used in receiving email. In this prompt, specify one of the domain names you will be using for your users. For example, if your email addresses are going to be [email protected] you would specify mydomain.com for this prompt. Don’t worry if you have multiple email addresses, we will cover that later on.

Configure Postfix to leverage MariaDB

First, let’s create a backup of the Postfix configuration, so we have a baseline to refer back to.

sudo cp /etc/postfix/main.cf /etc/postfix/main.cf.bak

Copy the following configuration and replace the domain name example.com with yours. Credit to linode for sharing their configuration as it not only defines integration into a database, but also hardens the Postfix deployment.

# See /usr/share/postfix/main.cf.dist for a commented, more complete version

# Debian specific:  Specifying a file name will cause the first
# line of that file to be used as the name.  The Debian default
# is /etc/mailname.
#myorigin = /etc/mailname

smtpd_banner = $myhostname ESMTP $mail_name
biff = no

# appending .domain is the MUA's job.
append_dot_mydomain = no

# Uncomment the next line to generate "delayed mail" warnings
#delay_warning_time = 4h

readme_directory = no

# TLS parameters
smtpd_tls_cert_file=/etc/letsencrypt/live/mydomain.com/fullchain.pem
smtpd_tls_key_file=/etc/letsencrypt/live/mydomain.com/privkey.pem
smtpd_use_tls=yes
smtpd_tls_auth_only = yes
smtp_tls_security_level = may
smtpd_tls_security_level = may
smtpd_sasl_security_options = noanonymous, noplaintext
smtpd_sasl_tls_security_options = noanonymous

# Authentication
smtpd_sasl_type = dovecot
smtpd_sasl_path = private/auth
smtpd_sasl_auth_enable = yes

# See /usr/share/doc/postfix/TLS_README.gz in the postfix-doc package for
# information on enabling SSL in the smtp client.

# Restrictions
smtpd_helo_restrictions =
        permit_mynetworks,
        permit_sasl_authenticated,
        reject_invalid_helo_hostname,
        reject_non_fqdn_helo_hostname
smtpd_recipient_restrictions =
        permit_mynetworks,
        permit_sasl_authenticated,
        reject_non_fqdn_recipient,
        reject_unknown_recipient_domain,
        reject_unlisted_recipient,
        reject_unauth_destination
smtpd_sender_restrictions =
        permit_mynetworks,
        permit_sasl_authenticated,
        reject_non_fqdn_sender,
        reject_unknown_sender_domain
smtpd_relay_restrictions =
        permit_mynetworks,
        permit_sasl_authenticated,
        defer_unauth_destination

# See /usr/share/doc/postfix/TLS_README.gz in the postfix-doc package for
# information on enabling SSL in the smtp client.

myhostname = example.com
alias_maps = hash:/etc/aliases
alias_database = hash:/etc/aliases
mydomain = mydomain.com
myorigin = $mydomain
mydestination = localhost
relayhost =
mynetworks = 127.0.0.0/8 [::ffff:127.0.0.0]/104 [::1]/128
mailbox_size_limit = 0
recipient_delimiter = +
inet_interfaces = all
inet_protocols = all

# Handing off local delivery to Dovecot's LMTP, and telling it where to store mail
virtual_transport = lmtp:unix:private/dovecot-lmtp

# Virtual domains, users, and aliases
virtual_mailbox_domains = mysql:/etc/postfix/mysql-virtual-mailbox-domains.cf
virtual_mailbox_maps = mysql:/etc/postfix/mysql-virtual-mailbox-users.cf
virtual_alias_maps = mysql:/etc/postfix/mysql-virtual-mailbox-aliases.cf,
        mysql:/etc/postfix/mysql-virtual-mailbox-users.cf

# Even more Restrictions and MTA params
disable_vrfy_command = yes
strict_rfc821_envelopes = yes
#smtpd_etrn_restrictions = reject
#smtpd_reject_unlisted_sender = yes
#smtpd_reject_unlisted_recipient = yes
smtpd_delay_reject = yes
smtpd_helo_required = yes
smtp_always_send_ehlo = yes
#smtpd_hard_error_limit = 1
smtpd_timeout = 30s
smtp_helo_timeout = 15s
smtp_rcpt_timeout = 15s
smtpd_recipient_limit = 40
minimal_backoff_time = 180s
maximal_backoff_time = 3h

# Reply Rejection Codes
invalid_hostname_reject_code = 550
non_fqdn_reject_code = 550
unknown_address_reject_code = 550
unknown_client_reject_code = 550
unknown_hostname_reject_code = 550
unverified_recipient_reject_code = 550
unverified_sender_reject_code = 550

Next, we need to create the mappings of domain names, users, and aliases. In the same directory as the main.cf (/etc/postfix) we need to first create a file that will tell postfix how to lookup what domain names exist. You can open the documents with your favorite text editor; I use vi since it’s universally installed.

sudo vi /etc/postfix/mysql-virtual-mailbox-domains.cf

Press i to get vi into insert mode and paste the following, replacing the password with the mailuser we specified earlier in this tutorial.

user = mailuser
password = mysupersecretpassword
hosts = 127.0.0.1
dbname = mailserver
query = SELECT 1 FROM virtual_domains WHERE name='%s'

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Next, we will create another file that is used to lookup each user’s mailbox.

sudo vi /etc/postfix/mysql-virtual-mailbox-users.cf

Press i to get vi into insert mode and paste the following, replacing the password with the mailuser we specified earlier in this tutorial.

user = mailuser
password = mysupersecretpassword
hosts = 127.0.0.1
dbname = mailserver
query = SELECT email FROM virtual_users WHERE email='%s'

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Last, we will create another file that is used to map an alias to a user’s mailbox.

sudo vi /etc/postfix/mysql-virtual-mailbox-aliases.cf

Press i to get vi into insert mode and paste the following, replacing the password with the mailuser we specified earlier in this tutorial.

user = mailuser
password = mysupersecretpassword
hosts = 127.0.0.1
dbname = mailserver
query = SELECT destination FROM virtual_aliases WHERE source='%s'

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Restart the Postfix service for the changes to take effect

sudo service postfix restart

Next, to enable port 587 and 465 to connect securely with email clients, we need to modify /etc/postfix/master.cf. First, let’s create a backup of the master.cf file.

sudo cp /etc/postfix/master.cf /etc/postfix/master.cf.bak

Next, we need to modify the master.cf file. Modify the document (mostly uncomment many of the lines) to look similar to the code below.

sudo vi /etc/postfix/master.cf
submission inet n       -       y       -       -       smtpd
  -o syslog_name=postfix/submission
  -o smtpd_tls_security_level=encrypt
  -o smtpd_sasl_auth_enable=yes
  -o smtpd_sasl_type=dovecot
  -o smtpd_sasl_path=private/auth
  -o smtpd_tls_auth_only=yes
  -o smtpd_reject_unlisted_recipient=no
  -o smtpd_recipient_restrictions=
  -o smtpd_relay_restrictions=permit_sasl_authenticated,reject
  -o milter_macro_daemon_name=ORIGINATING
smtps     inet  n       -       y       -       -       smtpd
  -o syslog_name=postfix/smtps
  -o smtpd_tls_wrappermode=yes
  -o smtpd_sasl_auth_enable=yes
  -o smtpd_sasl_type=dovecot
  -o smtpd_sasl_path=private/auth
  -o smtpd_reject_unlisted_recipient=no
  -o smtpd_recipient_restrictions=
  -o smtpd_relay_restrictions=permit_sasl_authenticated,reject
  -o milter_macro_daemon_name=ORIGINATING

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Restart the Postfix service for the changes to take effect

sudo service postfix restart

Configure Dovecot

Now that we have our MTA configured, we now need to configure our MDA. You can think of Postfix as a shipping center and Dovecot as the courier, who interfaces directly with your mailbox. Roundcube will be our MUA (mail user agent) that interfaces with Dovecot to display your mail. The goal for this section is to ensure Dovecot requires SSL.

First, we’ll create backups of each of the Dovecot configuration files

sudo cp /etc/dovecot/dovecot.conf /etc/dovecot/dovecot.conf.orig
sudo cp /etc/dovecot/conf.d/10-mail.conf /etc/dovecot/conf.d/10-mail.conf.orig
sudo cp /etc/dovecot/conf.d/10-auth.conf /etc/dovecot/conf.d/10-auth.conf.orig
sudo cp /etc/dovecot/dovecot-sql.conf.ext /etc/dovecot/dovecot-sql.conf.ext.orig
sudo cp /etc/dovecot/conf.d/10-master.conf /etc/dovecot/conf.d/10-master.conf.orig
sudo cp /etc/dovecot/conf.d/10-ssl.conf /etc/dovecot/conf.d/10-ssl.conf.orig

Execute the following command to enable support for imap and lmtp (pop3 can be added, but ensure you install the dovecot-pop3d package).

sudo sed -i '/^\!include_try \/usr\/share\/dovecot\/protocols.d\/\*.protocol/a protocols=imap lmtp' /etc/dovecot/dovecot.conf

Next, we need to edit /etc/dovecot/conf.d/10-mail.conf to define where mailboxes are stored. Execute the following commands:

sudo sed -i 's/mail_location = mbox.*/mail_location = maildir:\/var\/mail\/vhosts\/%d\/%n\//g' /etc/dovecot/conf.d/10-mail.conf
sudo sed -i 's/^#mail_privileged_group = mail/mail_privileged_group = mail/g' /etc/dovecot/conf.d/10-mail.conf

Next, we need to make directories for each of your domain names. Execute the following command for each of your domain names.

sudo mkdir -p /var/mail/vhosts/example.com

Now we need to create a user and group called vmail, assigned with an id of 5000, and set the directory with the owner of vmail

sudo groupadd -g 5000 vmail
sudo useradd -g vmail -u 5000 vmail -d /var/mail
sudo chown -R vmail:vmail /var/mail

Next we need to edit the user authentication file (/etc/dovecot/conf.d/10-auth.conf) to tell Dovecat to leverage MariaDB for our users. Execute the following commands:

sudo sed -i 's/^#disable_plaintext_auth = yes/disable_plaintext_auth = yes/g' /etc/dovecot/conf.d/10-auth.conf
sudo sed -i 's/^#auth_mechanisms = plain login/auth_mechanisms = plain login/g' /etc/dovecot/conf.d/10-auth.conf
sudo sed -i 's/^!include auth-system.conf.ext/#!include auth-system.conf.ext/g' /etc/dovecot/conf.d/10-auth.conf
sudo sed -i 's/^#!include auth-sql.conf.ext/!include auth-sql.conf.ext/g' /etc/dovecot/conf.d/10-auth.conf

Once we have the authentication file configured, we need to update the sql driver (/etc/dovecot/conf.d/auth-sql.conf.ext) to point to our mailboxes. You will need to uncomment the passdb section and uncomment the userdb driver that is static.

sudo vi /etc/dovecot/conf.d/auth-sql.conf.ext

Press i to get vi into insert mode and paste the following configuration

# Authentication for SQL users. Included from 10-auth.conf.
#
# <doc/wiki/AuthDatabase.SQL.txt>

passdb {
  driver = sql

  # Path for SQL configuration file, see example-config/dovecot-sql.conf.ext
  args = /etc/dovecot/dovecot-sql.conf.ext
}

# "prefetch" user database means that the passdb already provided the
# needed information and there's no need to do a separate userdb lookup.
# <doc/wiki/UserDatabase.Prefetch.txt>
#userdb {
#  driver = prefetch
#}

#userdb {
#  driver = sql
#  args = /etc/dovecot/dovecot-sql.conf.ext
#}

# If you don't have any user-specific settings, you can avoid the user_query
# by using userdb static instead of userdb sql, for example:
# <doc/wiki/UserDatabase.Static.txt>
userdb {
  driver = static
  args = uid=vmail gid=vmail home=/var/mail/vhosts/%d/%n
}

Press : and then type wq and press enter to write the changes to the file and quit in vi.

The final Dovecot file we need to modify will set our database settings (/etc/dovecot/dovecot-sql.conf.ext). Execute the following commands to uncomment the correct settings. Note: be sure to replace the password with the database password we configured earlier.

sudo sed -i 's/^#driver = /driver = mysql/g' /etc/dovecot/dovecot-sql.conf.ext
sudo sed -i 's/^#connect =/connect = host=127.0.0.1 dbname=mailserver user=mailuser password=mysupersecretpassword/g' /etc/dovecot/dovecot-sql.conf.ext
sudo sed -i 's/^#default_pass_scheme = MD5/default_pass_scheme = SHA512-CRYPT/g' /etc/dovecot/dovecot-sql.conf.ext
sudo sed -i '/^#password_query = \\/i password_query = SELECT email as user, password FROM virtual_users WHERE email=\x27%u\x27;' /etc/dovecot/dovecot-sql.conf.ext

After making the changes to the dovecot-sql.conf.ext file, next we need to change the owner and the group of the dovecot folder to the vmail user:

sudo chown -R vmail:dovecot /etc/dovecot
sudo chmod -R o-rwx /etc/dovecot

Next, we need to disable the unencrypted versions of IMAP and SMTP.

sudo vi /etc/dovecot/conf.d/10-master.conf

We need to edit the /etc/dovecot/conf.d/10-master.conf file and set ports to 0 to disable non-encrypted imap/pop3. Find service imap-login { and make it look like the following.

service imap-login {
  inet_listener imap {
    port = 0
  }
  inet_listener imaps {
    port = 993
    ssl = yes
  }

  # Number of connections to handle before starting a new process. Typically
  # the only useful values are 0 (unlimited) or 1. 1 is more secure, but 0
  # is faster. <doc/wiki/LoginProcess.txt>
  #service_count = 1

  # Number of processes to always keep waiting for more connections.
  #process_min_avail = 0

  # If you set service_count=0, you probably need to grow this.
  #vsz_limit = $default_vsz_limit
}

service pop3-login {
  inet_listener pop3 {
    port = 0
  }
  inet_listener pop3s {
    port = 995
    ssl = yes
  }
}

In the same file, find service lmtp { and replace the whole block down to the third } with the following:

service lmtp {
  unix_listener /var/spool/postfix/private/dovecot-lmtp {
    mode = 0600
    user = postfix
    group = postfix
  }

  # Create inet listener only if you can't use the above UNIX socket
  #inet_listener lmtp {
    # Avoid making LMTP visible for the entire internet
    #address =
    #port =
  #}
}

In the same file, find service auth { and replace the whole block down to the third } with the following:

service auth {
  # auth_socket_path points to this userdb socket by default. It's typically
  # used by dovecot-lda, doveadm, possibly imap process, etc. Users that have
  # full permissions to this socket are able to get a list of all usernames and
  # get the results of everyone's userdb lookups.
  #
  # The default 0666 mode allows anyone to connect to the socket, but the
  # userdb lookups will succeed only if the userdb returns an "uid" field that
  # matches the caller process's UID. Also if caller's uid or gid matches the
  # socket's uid or gid the lookup succeeds. Anything else causes a failure.
  #
  # To give the caller full permissions to lookup all users, set the mode to
  # something else than 0666 and Dovecot lets the kernel enforce the
  # permissions (e.g. 0777 allows everyone full permissions).
  unix_listener auth-userdb {
    mode = 0600
    user = vmail
    #group =
  }

  # Postfix smtp-auth
  unix_listener /var/spool/postfix/private/auth {
    mode = 0600
    user = postfix
    group = postfix
  }

  # Auth process is run as this user.
  user = dovecot
}

In the same file, find service auth-worker { and replace the whole block down to the } with the following:

service auth-worker {
  # Auth worker process is run as root by default, so that it can access
  # /etc/shadow. If this isn't necessary, the user should be changed to
  # $default_internal_user.
  user = vmail
}

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Last, we need to tell dovecot where our SSL certificate is for encryption. We will modify the /etc/dovecot/conf.d/10-ssl.conf file. Make sure to update the directory with the correct path for your certificates.

Execute the following commands, replacing

sudo sed -i 's/^ssl = yes/ssl = required/g' f
sudo sed -i 's/^ssl_cert = .*/ssl_cert = <\/etc\/letsencrypt\/live\/mydomain.com\/fullchain.pem/g' /etc/dovecot/conf.d/10-ssl.conf
sudo sed -i 's/^ssl_key = .*/ssl_key = <\/etc\/letsencrypt\/live\/mydomain.com\/privkey.pem/g' /etc/dovecot/conf.d/10-ssl.conf

Last, restart devocot to enable all of our changes.

sudo service dovecot restart

Configure Roundcube

Install dependencies for Roundcube

Roundcube requires several PHP PEAR modules. To install the bare minimum featureset, execute the following command:

sudo apt-get install php7.3-mbstring php-pear php-net-idna2 php-net-smtp  php-mail-mime

Create a database for Roundcube

First, we need to create a new database and user for Roundcube. We can do this by logging into MariaDB and executing the create and grant commands.

sudo mariadb -u myusername -p
CREATE DATABASE roundcubemail CHARACTER SET utf8 COLLATE utf8_general_ci;
GRANT ALL PRIVILEGES ON roundcubemail.* TO [email protected] IDENTIFIED BY 'myreallyreallysecretpassword';
FLUSH PRIVILEGES;
exit

Request SSL Certificates for Roundcube

We will want to ensure all traffic to and from the client is encrypted in transit when trying to access Roundcube. To do this, I leverage Let’s Encrypt, which will allow you to request a free SSL certificate. If you have your own SSL certificate, go ahead and copy it to a location on the server so we can reference it later.

sudo apt-get install certbot
sudo certbot certonly --authenticator standalone -d webmail.mydomain.com --pre-hook "service nginx stop" --post-hook "service nginx start"

Create a directory for Roundcube

We will need to create a directory that will hold Roundcube’s files to serve to the web. Let’s create a new directory to serve these files and limit permissions to www-data.

sudo mkdir /var/www/webmail.mydomain.com
sudo chown -R www-data:www-data /var/www/webmail.mydomain.com

Copy Roundcube Files to the web directory

We will need to grab the latest copy of Roundcube’s code to run the website. Note: please ensure you substitute the correct version for Roundcube when executing the commands below as the version listed in the guide will likely be out of date as time goes on:

cd /tmp
wget https://github.com/roundcube/roundcubemail/releases/download/1.4.1/roundcubemail-1.4.1.tar.gz
tar -xf roundcubemail-1.4.1.tar.gz
mv roundcubemail-1.4.1 /var/www/webmail.mydomain.com

Populate the SQL Database

You will need to execute the following SQL command to populate your Roundcube database with the tables needed to run Roundcube. To do so, execute the following commands.

sudo mariadb roundcubemail < /var/www/webmail.mydomain.com/SQL/mysql.initial.sql

Install Roundcube dependencies

Roundcube doesn’t ship with several javascript dependencies. To ensure the Roundcube pages load properly, you will need to execute the following command to pull down the javascript dependencies.

sudo php /var/www/webmail.mydomain.com/bin/install-jsdeps.sh

Configure NGINX

Let’s configure NGINX to point to our web directory for the website. When doing so, it is very important you protect your installation by preventing access to some sensitive files from the web.

First, create a virtual-host file within the nginx sites-available folder:

sudo vi /etc/nginx/sites-available/webmail.mydomain.com

Press i to get vi into insert mode and paste the following. Note: Please replace the values with the path to your SSL Certificate we generated earlier.

##
# You should look at the following URL's in order to grasp a solid understanding
# of Nginx configuration files in order to fully unleash the power of Nginx.
# https://www.nginx.com/resources/wiki/start/
# https://www.nginx.com/resources/wiki/start/topics/tutorials/config_pitfalls/
# https://wiki.debian.org/Nginx/DirectoryStructure
#
# In most cases, administrators will remove this file from sites-enabled/ and
# leave it as reference inside of sites-available where it will continue to be
# updated by the nginx packaging team.
#
# This file will automatically load configuration files provided by other
# applications, such as Drupal or WordPress. These applications will be made
# available underneath a path with that package name, such as /drupal8.
#
# Please see /usr/share/doc/nginx-doc/examples/ for more detailed examples.
##

# Default server configuration
#

server {
        listen 443 ssl;
        listen [::]:443 ssl;
        server_name webmail.mydomain.com;

ssl_certificate /etc/letsencrypt/live/webmail.mydomain.com/fullchain.pem;
  ssl_certificate_key /etc/letsencrypt/live/webmail.mydomain.com/privkey.pem;
  ssl_session_timeout 1d;
  ssl_session_cache shared:SSL:50m;
  ssl_session_tickets off;
  ssl_protocols TLSv1.1 TLSv1.2;
  ssl_ciphers 'ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-AES256-GCM-SHA384:DHE-RSA-AES128-GCM-SHA256:DHE-DSS-AES128-GCM-SHA256:kEDH+AESGCM:ECDHE-RSA-AES128-SHA256:ECDHE-ECDSA-AES128-SHA256:ECDHE-RSA-AES128-SHA:ECDHE-ECDSA-AES128-SHA:ECDHE-RSA-AES256-SHA384:ECDHE-ECDSA-AES256-SHA384:ECDHE-RSA-AES256-SHA:ECDHE-ECDSA-AES256-SHA:DHE-RSA-AES128-SHA256:DHE-RSA-AES128-SHA:DHE-DSS-AES128-SHA256:DHE-RSA-AES256-SHA256:DHE-DSS-AES256-SHA:DHE-RSA-AES256-SHA:!aNULL:!eNULL:!EXPORT:!DES:!RC4:!3DES:!MD5:!PSK';
  ssl_prefer_server_ciphers on;
  ssl_stapling on;
  ssl_stapling_verify on;
  ssl_trusted_certificate /etc/letsencrypt/live/webmail.mydomain.com/chain.pem;


        # SSL configuration
        #
        # listen 443 ssl default_server;
        # listen [::]:443 ssl default_server;
        #
        # Note: You should disable gzip for SSL traffic.
        # See: https://bugs.debian.org/773332
        #
        # Read up on ssl_ciphers to ensure a secure configuration.
        # See: https://bugs.debian.org/765782
        #
        # Self signed certs generated by the ssl-cert package
        # Don't use them in a production server!
        #
        # include snippets/snakeoil.conf;

        root /var/www/webmail.mydomain.com;

        # Add index.php to the list if you are using PHP
        index index.php index.html index.htm;

       # Revoke access to sensitive files and directories
       location ~ ^/(README|INSTALL|LICENSE|CHANGELOG|UPGRADING)$ {
                deny all;
       }
       location ~ ^/(config|temp|bin|SQL|logs)/ {
                deny all;
       }

        # pass PHP scripts to FastCGI server
        #
        location ~ \.php$ {
                include snippets/fastcgi-php.conf;
        #
        #       # With php-fpm (or other unix sockets):
                fastcgi_pass unix:/run/php/php7.3-fpm.sock;
        #       # With php-cgi (or other tcp sockets):
        #       fastcgi_pass 127.0.0.1:9000;
        }

        # deny access to .htaccess files, if Apache's document root
        # concurs with nginx's one
        #
        location ~ /\. {
                deny all;
                access_log off;
                log_not_found off;
       }
}

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Last, we need to create a link of the virtual host file to /etc/nginx/sites-enabled. You will need to execute the following commands to create the link as well as restart nginx to apply the changes.

sudo ln -s /etc/nginx/sites-available/webmail.mydomain.com /etc/nginx/sites-enabled/webmail.mydomain.com
sudo service nginx restart

Run the Roundcube installer

At this point, if you navigate to https://webmail.mydomain.com/installer, you should see the Roundcube Webmail Installer page. You should see a series of items show OK, NOT AVAILABLE, or NOT OK. You will need to remediate any items that show NOT OK for Roundcube to successfully run.

In this installer, I primarily focused on Step 1 (Checking the environment) and Step 2 (Checking the database). Once both show OK (don’t worry about if email is successful or fails (likely it is failing still), move the installer directory to your home drive to secure the environment (IT IS VERY DANGEROUS TO LEAVE THIS PAGE!!! DON’T SKIP THIS STEP).

sudo mv /var/www/webmail.mydomain.com/installer ~

Update Roundcube configuration

I couldn’t get Roundcube to actually work during the installation with this setup until I manually specified a few items via the Roundcube configuration file. Within the /var/www/webmail.mydomain.com/config/config.inc.php file, ensure you have the following code snippets to allow Roundcube to properly authenticate to your mailserver.

sudo vi /var/www/webmail.mydomain.com/config/config.inc.php

Ensure you have the following code snippets (typically there is a section under // IMAP that has the config we can start with). To do so, press i to get vi into insert mode and paste the following.

$config['default_port'] = 993;
$config['default_host'] = 'imaps://localhost';
$config['mail_domain'] = '%d';
$config['imap_conn_options'] = array(
 'ssl'         => array(
     'verify_peer'       => true,
     'verify_peer_name' => false,
  ),
);

// SMTP
$config['smtp_server'] = 'ssl://localhost';
$config['smtp_port'] = 465;
$config['smtp_auth_type'] = 'LOGIN';
// Required if you're running PHP 5.6 or later
$config['smtp_conn_options'] = array(
    'ssl' => array(
        'verify_peer'      => true,
        'verify_peer_name' => false,
    ),
);

Press : and then type wq and press enter to write the changes to the file and quit in vi.

Verify

At this point, you should be able to login to https://webmail.mydomain.com and send/receive email!

As with all technology, ensure you keep up-to-date with all the latest security patches to keep your environment stable and secure.

If you made it to this point, were able to successfully send/receive mail via Roundcube, pat yourself on the back and grab a fine beverage!

Troubleshooting

Here are some useful commands to help troubleshoot your deployment.

sudo postqueue -p can be used to check if any pending emails are queued.

sudo postmap -q mydomain.com mysql:/etc/postfix/mysql-virtual-mailbox-domains.cf can be used to validate what domain names are accepted. You should receive the value of 1 if it exists.

sudo postmap -q [email protected] mysql:/etc/postfix/mysql-virtual-mailbox-users.cf will validate if a user account exists with the specified email address. You should receive the value of the email address of the user if it exists.

sudo postmap -q [email protected] mysql:/etc/postfix/mysql-virtual-mailbox-aliases.cf can be used to validate the alias of an email address. You should receive the email address of the user account if it does map back to another user.

tail -f /var/log/mail.log can be useful watching how emails are handled by postfix/dovecot to troubleshoot how messages are being handled

Roundcube installation instructions (documentation): https://github.com/roundcube/roundcubemail/wiki/Installation

How to install NodeJS on a Raspberry Pi

Installing NodeJS on a Raspberry Pi can be a bit tricky.  Over the years, the ARM based processor has gone through several versions (ARMv6, ARMv7, and ARMv8), in which there are different flavors of NodeJS to each of these architectures.

Depending on the version you have, you will need to manually install NodeJS vs grabbing the packages via a traditional apt-get install nodejs.

Step 1: Validate what version of the ARM chipset you have

First let’s find out what ARM version you have for your Raspberry Pi.¬† To do that, execute the following command:

uname -m

You should receive something like: armv61

Step 2: Find the latest package to download from nodeJS’s website

Navigate to¬†https://nodejs.org/en/download/ and scroll down to the latest Linux Binaries for ARM that match your instance.¬† Right click and copy the address to the instance that matches your processor’s architecture.¬† For example, if you saw armv61, you’d copy the download for ARMv6

Step 3: Download and install nodeJS

Within your SSH/console session on the Raspberry Pi, change to your local home directory and execute the following command (substituting in the URL you copied in the previous step in what’s outlined in red below).¬† For example:

cd ~
wget https://nodejs.org/dist/v8.11.3/node-v8.11.3-linux-armv6l.tar.xz

Next, extract the tarball (substituting in the name of the tarball you downloaded in the previous step) and change the directory to the extracted files

tar -xvf node-v8.11.3-linux-armv6l.tar.xz
cd node-v8.11.3-linux-armv6l

Next, remove a few files that aren’t used and copy the files to /usr/local

rm CHANGELOG.md LICENSE README.md
cp -R * /usr/local/

Step 4: Validate the installation

You can validate that you have successfully installed NodeJS by running the following commands to return the version numbers for NodeJS and npm

node -v
npm -v

That’s it!¬† Have fun!



How to build a LEMP stack

Growing up it was always common to spin up a “LAMP” box to host a website.  The typical setup was:
Linux
Apache
MySQL
PHP

Over the past few years, this model has slightly changed due to new open source technologies bringing new ideas to solve performance and licensing issues at massive scale.  In this tutorial, we are going to look at setting up a LEMP box on Debian Stretch (9.1).
Linux
nginx [engine x]
MariaDB
PHP

Please note, MariaDB could easily be swapped out with MySQL in this tutorial, however many have opted to jump over to MariaDB as an open source alternative (actually designed by the original developers of MySQL) over fear Oracle may close source MySQL.

Installing Linux

This tutorial assumes you already have either a copy of Ubuntu 14+ or Debian 7+.  This probably works on earlier versions as well, but I haven’t tested them.  On a side note, I typically don’t install Linux builds with an interactive desktop environment, so grab yourself a copy of Putty and ssh in or open up Terminal if you have interactive access to the Desktop Environment.  Before continuing, go ahead and update apt-get repos and upgrade any packages currently installed:

apt-get update && apt-get upgrade

Installing nginx

Grab a copy of nginx

apt-get install nginx

Installing MariaDB

Grab a copy of MariaDB

apt-get install mariadb-server

Installing PHP

In this case, I want to roll with PHP7.  You can specify php5 or php7 depending on your application, but PHP7 has some great performance enhancements, so for new apps, I’d leverage it.  The biggest thing here is to make sure you use the FastCGI Process Manager package.  If you specify just php or php7, package manager will pull down apache2 as a dependency.  That is not what we want in our LEMP stack.

apt-get install php7.3-fpm

Once installed, fire up your favorite text editor (it’s ok if it’s vi :)) and edit the default site for nginx

vi /etc/nginx/sites-enabled/default

Search for the comment # Add index.php to the list if you are using PHP and add index.php to the line below it.  For example:

index index.html index.htm index.php index.nginx-debian.html;

Next, find the comment # pass PHP scripts to FastCGI server and change the block of code to the following to tell nginx to process .PHP files with FastCGI-PHP:

# pass PHP scripts to FastCGI server
#
location ~ \.php$ {
include snippets/fastcgi-php.conf;
#
# # With php-fpm (or other unix sockets):
fastcgi_pass unix:/var/run/php/php7.3-fpm.sock;
# # With php-cgi (or other tcp sockets):
# fastcgi_pass 127.0.0.1:9000;
}

Save the file.  If using vi, you can do that by executing :wq

Next, reload the nginx service to pickup the new changes to our configuration:

service nginx reload

Test

At this point, we can create a php file to validate things are working well. Go ahead and create a new file /var/www/html/info.php and add the following line:

<?php
phpinfo();

If you see a page listing the PHP version and the corresponding environment configuration, congratulations, you have finished setting up your new LEMP stack! ūüôā

[Tutorial] Adding firewall rules via system-config-firewall-tui on CentOS 6

Here is a quick tutorial on how to add an ingress firewall rule on your CentOS 6 machine.  In this example, we will be forwarding port 443 for HTTPS.

  1. Open up terminal if you are on the GUI version of CentOS 6
    CentOS6 - Terminal
  2. Execute the following command
    1. system-config-firewall-tui
      Terminal - system-config-firewall-tui
  3. Use your arrow keys to select Customize and hit enter
    system-config-firewall-tui - Customize Rules
  4. Use your arrow keys to select which service you would like to allow.  Hit the spacebar to enable or disable the rule and then select Close once you have enabled/disabled the rules you wish.
    1. In this case, I arrowed down to HTTPS and hit the spacebar.
      system-config-firewall-tui - Select Rules
  5. Select OK
    system-config-firewall-tui - Apply Rules
  6. Select Yes
    system-config-firewall-tui - Apply Rules - Confirmation

[Tutorial] How-to install VMTools on CentOS 6

Here is a quick tutorial on how to get VMware Tools up and running on a CentOS 6 Linux machine. ¬†Although the instructions are shown with the GUI, we’ll use terminal so the guide works with both gui and non-gui based installs.

  1. Mount the VM tools installer to your VM
    Install-Upgrade VMware Tools
  2. Open up Terminal
    CentOS6 - Terminal
  3. Execute the following command (this will create a mount point for our CD drive)
    1. mkdir /cdrom
      CentOS6 - VMware Tools - New Mount Point
  4. Execute the following command (this will map the CD drive to our cdrom mount point)
    1. mount /dev/cdrom /cdrom
      CentOS6 - VMware Tools - Map Mount Point cdrom
  5. Execute the following command to move to your temporary files folder
    1. cd /tmp
      CentOS6 - VMware Tools - Temporary Files
  6. Execute the following command to extract the VMware Tools tarball
    1. tar -xvf /cdrom/VMwareTools (tab to autofill the rest of the package)
      CentOS6 - VMware Tools - Extract VMware Tools
  7. Execute the following command to run the VMware Tools installer
    1.  ./vmware-tools-distrib/vmware-install.pl
      CentOS6 - VMware Tools - Install VMware Tools
  8. Press Enter/Return through each of the questions, using their defaults
    CentOS6 - VMware Tools - Install Default Values
    CentOS6 - VMware Tools - Install Default Values Continued
    CentOS6 - VMware Tools - Install Default Values Continued Continued
  9. Verify VMtools is running by looking at the client status in vSphere
    CentOS6 - VMware Tools - vSphere Status

Set static IP on CentOS 6 via command line

Here is how to configure a static IP on CentOS 6 via command line.

  1. Determine which interface you want to configure–in this example, I will be using eth0
    1. ifconfig -a
    2. Show all linux interfaces
  2. Edit the interface you wish to configure (I’ll use nano as vi requires some knowledge for beginner Linux users)
    1. nano /etc/sysconfig/network-scripts/ifcfg-eth0
    2. nano ifcfg-eth0
  3. Use the following settings and then use Control+O to Save and Control+X to Exit
    1. nano /etc/sysconfig/network-scripts/ifcfg-eth0
    2. DHCPCLASS=
      IPADDR=192.168.1.100
      NETMASK=255.255.255.0
      ONBOOT=yes
      BOOTPROTO=STATIC
    3. static IP CentOS
  4. Next, let’s configure the hostname and default gateway. ¬†We will use nano again to edit the file.
    1. nano /etc/sysconfig/network
    2. Ensure GATEWAY=192.168.1.1 has been set
    3. Static Gateway
  5. Next, let’s configure our DNS servers to resolve domain names (in this case, I will set mine to use Google’s DNS servers)
    1. nano /etc/resolv.conf
    2. nameserver 8.8.8.8
      nameserver 8.8.4.4
    3. static nameservers
  6. Restart the networking service for the changes to take effect
    1. /etc/init.d/network restart
    2. restart interface

sh: /usr/bin/vmware-config-tools.pl: Permission denied VMware Tools Linux

Symptom: You see the following permissions error when trying to install VMware Tools on a Linux OS regardless if you are running as su or root:

[[email protected] vmware-tools-distrib]# ./vmware-install.pl
Creating a new VMware Tools installer database using the tar4 format.

Installing VMware Tools.

In which directory do you want to install the binary files?
[/usr/bin]

What is the directory that contains the init directories (rc0.d/ to rc6.d/)?
[/etc/rc.d]

What is the directory that contains the init scripts?
[/etc/rc.d/init.d]

In which directory do you want to install the daemon files?
[/usr/sbin]

In which directory do you want to install the library files?
[/usr/lib/vmware-tools]

The path “/usr/lib/vmware-tools” does not exist currently. This program is
going to create it, including needed parent directories. Is this what you want?
[yes]

In which directory do you want to install the documentation files?
[/usr/share/doc/vmware-tools]
The path “/usr/share/doc/vmware-tools” does not exist currently. This program
is going to create it, including needed parent directories. Is this what you
want? [yes]

The installation of VMware Tools 9.0.5 build-1137270 for Linux completed
successfully. You can decide to remove this software from your system at any
time by invoking the following command: “/usr/bin/vmware-uninstall-tools.pl”.

Can’t exec “/usr/lib/vmware-tools/bin/configure-gtk.sh”: Permission denied at ./vmware-install.pl line 3955.
Before running VMware Tools for the first time, you need to configure it by
invoking the following command: “/usr/bin/vmware-config-tools.pl”. Do you want
this program to invoke the command for you now? [yes]

sh: /usr/bin/vmware-config-tools.pl: Permission denied
/sbin/restorecon:  Warning no default label for /tmp/vmware-block-restore0/tmp_file
[[email protected] vmware-tools-distrib]#

CentOS VMware Tools Permission Error

Solution: You need to extract the files from the tarball when installing the guest tools via the tar command rather than the build in Archive Manager installed with the OS.

  1. Mount the VMware Tools to the VM
  2. Copy the VMware Tools tarball to the desktop of the Linux OS
    Copy VMwareTools
  3. Execute the following command to extract the tar’s contents
    1. tar -zxvf VMwareTools-9.0.5-1137270.tar.gz
  4. Change directories to the vmware-tools-distrib that was just extracted from the tarball and execute the following commands to begin the installation
    1. cd vmware-tools-distrib
    2. ./vmware-install.pl
      vmware-install.pl

Setting up Java Runtime Environment 7 (JRE7) on Ubuntu 12.04 via Command Line

Need Java to run an application on your Linux workstation/server?  Follow the steps below via the terminal to install the latest version of Java.

  1. Head over to http://www.java.com/en/download/manual.jsp to find the latest Linux download from your client machine.
  2. Look at the link for the latest Java release for Linux.  Since we are using Ubuntu we do not need the RPM release.  In this case, I will be downloading Java 1.7.0_25-b15 for Linux x64.
    1. The download url is http://javadl.sun.com/webapps/download/AutoDL?BundleId=78697
  3. Head over to the Linux terminal on the machine you want to install Java on, and execute the following command to download the files from Java’s website
    1. wget http://javadl.sun.com/webapps/download/AutoDL?BundleId=78697
  4. Extract the tarball.  Since wget cannot pull the filename like a modern webrbowser, you will have to reference the weird filename AutoDL?BundleId=78697
    1. tar -xvzf AutoDL?BundleId=78697
  5. Find out what the name of the folder is of the java files you extracted by listing the files in the current directory.  At the time of writing this, the extracted folder I had was jre1.7.0_25, so I will continue to reference that moving forward.
    1. ls
  6. Create a folder in the usr folder for Java to reside.
    1. sudo mkdir /usr/java/
  7. Move the files we extracted Java files to the java folder
    1. sudo mv jre1.7.0_25/ /usr/java/
  8. Execute the following to enable the Java Runtime Environment
    1. sudo update-alternatives –install /usr/bin/java java /usr/java/jre1.7.0_25/bin/java¬†1
  9. Execute the following command to set the default Java to use
    1. sudo update-alternatives –config java
  10. Execute the following command to verify that the latest version of java is installed
    1. java -version
  11. Remove the tarball we downloaded from Java’s website to free up some space
    1. rm ~/AutoDL?BundleId=78697

Install Self-Signed CA Certificates on Ubuntu 12.04 via Command Line

Copy your .crt files to /usr/share/ca-certificates

Run: sudo update-ca-certificates

Hit yes to trust the certificates in the wizard (text based for CLI), and away you go! ūüôā
